Description
Machine length: 2560 mm
Machine width: 800 mm
Machine height: 2115 mm
Weight: 460 kg
Max. gluing frame: 2130 x 1520 mm
Max. gluing desk: 2400 x 980 mm
Supporting beams: 1 x 1960 2 x 970 mm
Number of pressing units: 5 pcs
Pressing valves stroke: 120 mm
Axis pressing unit setting: fixed pitch 90° angle
Variable pitch: ± 45° angle
Pressing 1 cylinder: 1, 5 t
Electrohydraulic unit power: 0, 75 kW
Input pressure setting: 10 – 150 BAR
