Description
Machine length: 7200 mm
Machine width: 1100 mm
Machine height: 1600 mm
Weight: 2240 kg
Max. material length: 3050/6050 mm
Max. material thickness: 20 – 50 mm
Gluing material width: 40 – 150 mm
Air pressure: 0, 4 – 0, 6 MPa
Pressing pressure: 2 – 5, 5 t
Circuit pressure: 4 – 20 MPa
Saw power: 1, 1 kW
Electrohydraulic power: 1, 5 kW
Average production: 6 – 9 m/min
